BMW K1200GT touring motorcycle with full fairing
A motorcycle fairing is a shell placed over the frame of some motorcycles, especially racing motorcycles and sport bikes, with the primary purpose to reduce air drag. The secondary functions are the protection of the rider from airborne hazards and wind-induced hypothermia and of the engine components in the case of an accident. There may be a front fairing, as well as a rear fairing component. A motorcycle windshield may be an integral part of the fairing.
The major benefit of a fairing on sport touring and touring motorcycles is a reduction in fuel consumption. The reduction in aerodynamic drag allows for taller gearing, which in turn increases engine life.
The importance of streamlining was known very early in the 20th century. Some streamlining was seen on racing motorcycles as early as the 1920s. The effects of aerodynamic drag on motorcycles are very significant.
The term fairing came into use in aircraft aerodynamics with regard to smoothing airflow over a juncture of components where airflow was disrupted. Early streamlining was often unsuccessful resulting in instability. Handlebar fairings, such as those on Harley-Davidson Tourers, sometimes upset the balance of a motorcycle, inducing wobble. The first factory installed full fairing was that installed on the BMW R100RS introduced in 1976. This marked the beginning of widespread adoption of fairings on sports, and touring types of motorcycles.
Originally the fairings were cowlings put around the front of the bike, increasing its frontal area. Gradually they had become an integral part of the design. Modern fairings increase the frontal area at most by 5% compared to a naked machine. Fairing may carry headlights, instruments, and other items. If the fairing is mounted on the frame, mounting equipment on the fairing reduces the weight and rotational inertia of the steering assembly, improving the handling
Types
Streamliner: This is a full fairing as found on land speed record machines. The entire body of the motorcycle is covered to provide the lowest drag coefficient ratio attainable. The NSU Dolphin II (Delphin II) is a streamliner.
Dustbin fairing: A single-piece, streamlined shell covering the front half of a motorcycle resembling the nose of an aircraft, sometimes referred to as torpedo fairing. It dramatically reduced the frontal drag, but it was banned by Fédération Internationale de Motocyclisme (FIM) from racing in 1958, because it was thought that the frontal point of wind pressure made them highly unstable even with small amounts of yaw.Other reasons cited for the ban were to ensure adequate steering range (lock-to-lock) and stability against crosswinds. FIM regulations forbid streamlining beyond the wheel spindles and require the rider's arms and legs to be visible from the side.
Dolphin fairing: It was called so because in early models the front wheel mud guard streamlined with the rising windshield part of the fairing resembled the dolphin's beak from the side view. They had become the norm since the ban of the dustbins
Harley-Davidson police motorcycle with "batwing" fairing
Full-fairing: Bodywork that covers both upper and lower portions of the motorcycle, as distinct from a half fairing, which only has an upper section, and the lower half of the motorcycle is exposed. The fairing on a race or sport bike is meant as an aerodynamic aid, so the windscreen is rarely looked through. If the rider is sitting up at speed he will be buffeted by his rapid progress through the air and act as a parachute, slowing the bike, while if the rider lies flat on the tank behind the windscreen he generates much less aerodynamic drag. The high windscreen and handle-bar width of a touring fairing protect the upright rider from the worst of this, and the windscreen is functional. Full fairings can also provide protection to the engine and chassis in the event of a crash where the fairings, rather than the engine covers and/or frame, slide on the road.
Suzuki SV650s with half fairing and an aftermarket belly pan.
Half-fairing: Fairing that features a windscreen and fairing extending at least below the handlebars, even as far as down to the sides of the cylinder block, though generally half-fairing doesn't cover the sides of the crankcase or gear box. A number of half-faired models have aftermarket kits available to extend the original half-fairing into a full fairing. Due to the popularity of these kits some manufacturers have started to supply their own full-fairing conversion kits and even offer their half-faired models new with a full-fairing kit fitted at the factory.
Quarter fairing: A windscreen and minimal fairing extending around the headlight fixed to the triple clamp; also referred to as a "bikini fairing".
Belly pan: Quarter and half fairings are often paired with a belly pan below the engine for diverting air flow away from under the engine to reduce aerodynamic lift, as well as cosmetic reasons. Some track day or racing rules require belly pans to catch leaked fluids
